Framed SMT Stencils

Framed SMT Stencils

0 Customer Reviews
24-Hour Turn
Quick Overview
These solder paste stencils are designed for high volume screen printing on printed circuit boards.
  • Foils are permanently mounted into aluminum frames
  • Provide optimum solder paste volume control
  • Large variety of standard frames for every printer
** Framed stencils have smooth aperture walls and can be used for 16 Mil pitch and below and for Micro BGA's.
starting at $185.00
Your selection is: Framed SMT Stencils
Unit Price: $185.00
Total
12344

Stencil Form

Zip File ( Gerber(s) or DFX )
(e.g. SPR-25, Custom, N/A)

Overview

Framed SMT Stencils or glue-in stencils are laser cut solder paste stencil foils permanently mounted in a stencil frame using a mesh border to tightly stretch the stencil foil taut in the frame. Framed SMT Stencils are designed for high volume screen printing on printed circuit boards. All of our laser cut stencils provide optimum solder paste volume control. Framed SMT Stencils have smooth aperture walls and can be used for 16 Mil pitch and below and for Micro BGA"s.

We fabricate Framed SMT stencils for a variety of stencil printers.

Key features:

  • Unique Process for Smooth Aperture Walls
  • Very Clean Laser-Cut Apertures
  • Excellent Print Performance
  • Excellent for High-Volume Stencil Printing on printed circuit boards
  • Unique Process Creates Permanent Non-removable Non-fading Fiducial
  • All Framed SMT Stencils are Double Bonded to Extreme Wear.
AVAILABLE FRAMES
Frame Size Max. Foil Size Max. Image Size Price
Cast 8"x10" 6"x8" 4"x6" $185.00
Cast 10"x10" 8"x8" 6"x6" $185.00
Cast 12"x12" 10"x10" 8"x8" $185.00
Cast 12"x17" 10"x15" 8"x13" $185.00
Cast 15"x15" 13"x13" 11"x11" $185.00
Ext. 20"x20" (OD 23"x23") 19"x19" 17"x17" $245.00
Ext. 29"x29" 25"x22" 23"x20" $245.00

**Cast frames are solid aluminum.
**Extruded frames are hollow.

Specs

Technology 100% laser cut
Material used Stainless Steel
Stencil thickness .002 - .016 inches
Minimum cut width .002 inches
Maximum size 29"x29" inches
Aperture tolerance within .00025 inches
Allow for Fiducial Data Yes
Allow for panelized data Yes
