Purchase ViewMate Deluxe today and we'll give you a $95 Coupon
**Redeemable for $95 off your next US QuickTurn PCB order**
*Upgrade Option: If you already have a license of ViewMate Deluxe and are looking to purchase an Add-On Module, please select the option that indicates you already have a license of ViewMate Deluxe and proceed to Add-On Modules section to make your selection. You will also be asked to enter the Serial Number of your existing license.
*Pick 3 Modules and Receive 1 of them FREE
Buy ViewMate Deluxe today and we'll give you a ** $95 Coupon Redeemable for $95 off your next US QuickTurn Prototype PCBs order **
››› ViewMate Deluxe - Computer Locked - $95.00* We issue you a license file that locks ViewMate Deluxe to a single computers ethernet card.
››› ViewMate Deluxe - USB Dongle - Single User - $245.00* We provide you a USB dongle. ViewMate Deluxe can be installed on multiple computers but will only run on a computer that has the dongle plugged in.
››› ViewMate Deluxe - USB Dongle - 5 User Network - $450.00* We provide you a USB dongle to plug into your server. ViewMate Deluxe can be installed and run on any computer connected to your network. The allowed number of users running ViewMate Deluxe simultaneously is set to the number of users you purchased.
* Includes 1 year free upgrades and technical support.
For questions about ViewMate Deluxe please contact us
Produce perfect manufacturing files every time with the built in Smart DFM module. Whether you're a designer that wants to check the output from his CAD system, or needs to edit the job, to the board shop that needs to get their jobs done accurately and in a timely manner; ViewMate Deluxe, with Smart DFM is the tool for you.
