SMT Stencils

These laser cut stencils are specifically designed to manually print solder paste onto circuit boards

• Eliminates tedious hand soldering of prototype circuit boards
• Reduce circuit board assembly time
• Comes with flaps to contain and control the paste application

** Stencil Kit comes with a squeegee blade and board holder.

** Our process using a Toaster Reflow Oven will make your prototype circuit board assembly easier and save you time.

** We back up that with a money-back guarantee program.

The universal stencil fixture was designed to be used with a stainless steel frameless SMT stencil to print solder paste on printed circuit boards. It is basically a manual stencil printer but it costs a fraction of the price.

These laser cut stencils are designed to work with stencil tensioning systems also known as Reusable Stencil Frames like the Wizard Frame.

• Reduces storage space requirements
• Significantly less expense than framed stencils
• Smooth aperture walls and can be used for 16 Mil pitch and below and for Micro BGA's

** Frameless SMT Stencils are recommended for prototype printed circuit board assembly or short runs.

These solder paste stencils are designed for high volume screen printing on printed circuit boards.

• Foils are permanently mounted into aluminum frames
• Provide optimum solder paste volume control
• Large variety of standard frames for every printer

** Framed stencils have smooth aperture walls and can be used for 16 Mil pitch and below and for Micro BGA's.
